Rigging self-aligning swivel

Rigging self-aligning swivel

- Power on: 220 / 380V
- Capacity:
- Origin: Malaysia

  • Application

Specifications:

- A device with rotating function, used for automatic welding details rotation axis.

- Equipment automatically change according to diameter tank.

- Equipment can be combined initiative from the rollers, roller automatically. Number of rollers initiative, roller passive depending on the length of the object being welded.

Model

Maximum load capacity (kg

Workpiece size (mm)

YR20

20000

Ф580-4500

YR30

30000

Ф580-4500

YR40

40000

Ф580-4500

YR60

60000

Ф580-4500

YR90

90000

Ф580-4500

YR120

120000

Ф580-4500

  • Note: Manufacturer may change design and specifications as required by the user.
